| भाग नम्बर | 990000738 |
| ब्रान्ड | TPO |
| साइज | 3.5 |
| आवेदन | DSC |
| संकल्प | 320×240 |
| रचना | LCM |
| चमक | 350 |
| CR | 500:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | Serial RGB |
| प्यानल ब्रान्ड | TPO |
| प्यानल मोडेल | 990000738 |
| प्यानल प्रकार | LTPS TFT-LCD , LCM |
| प्यानल आकार | 3.5 inch |
| संकल्प | 320(RGB)×240 , QVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 76.84×43.2 mm |
| रूपरेखा | 89.5×51.76×2.9 mm |
| सतह | Hard coating (3H) |
| चमक | 350 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193140% |
| प्रतिक्रिया समय | 5/11 (Typ.)(Tr/Td) |
| हेर्ने कोण | 60/60/55/60 (Typ.)(CR≥10)(L/R/U/D) |
| बत्ती प्रकार | 4S1PWLEDWithout Driver |
| संकेत इन्टरफेस | Serial RGB (8-bit) + SPI, 39 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | DSC |
