| भाग नम्बर | A080SN01 V8 |
| ब्रान्ड | AUO |
| साइज | 8.0 |
| आवेदन | DPF |
| संकल्प | 800×600 |
| रचना | LCM |
| चमक | 250 |
| CR | 500:1 |
| रंगहरू | 262K/16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | TTL |
| प्यानल ब्रान्ड | AUO |
| प्यानल मोडेल | A080SN01 V8 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 8.0 inch |
| संकल्प | 800(RGB)×600 , SVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 162×121.5 mm |
| रूपरेखा | 183×141 mm |
| सतह | Antiglare, Hard coating (3H) |
| चमक | 250 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| प्रतिक्रिया समय | 4/16 (Typ.)(Tr/Td) |
| हेर्ने कोण | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| बत्ती प्रकार | 3S8PWLEDWithout Driver |
| संकेत इन्टरफेस | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| इनपुट भोल्टेज | 3.3/11.68/15/-6.75V (Typ.)(VCC/AVDD/VGH/VGL) |
| आवेदन | DPF |
