| भाग नम्बर | AT070TNA2 V.1 |
| ब्रान्ड | Innolux |
| साइज | 7.0 |
| आवेदन | MP4 |
| संकल्प | 1024×600 |
| रचना | LCM |
| चमक | 250 |
| CR | 700:1 |
| रंगहरू | 262K/16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | CHIMEI INNOLUX |
| प्यानल मोडेल | AT070TNA2 V.1 4 Compatible model |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 7.0 inch |
| संकल्प | 1024(RGB)×600 , WSVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 153.6×90 mm |
| रूपरेखा | 165.75×105.39×3.7 mm |
| सतह | Glare (Haze 0%), Hard coating |
| चमक | 250 cd/m² (Typ.) |
| विपरीत अनुपात | 700:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.7M (6-bit / 6-bit + Dithering) |
| प्रतिक्रिया समय | 10/15 (Typ.)(Tr/Td) |
| हेर्ने कोण | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 3S6PWLEDWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 6/8-bit), 40 pins |
| इनपुट भोल्टेज | 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| आवेदन | MP4 |
| AT070TN07 V.A | Innolux | 7.0 | 480×234 |
| AT070TN82 | Innolux | 7.0 | 800×480 |
| AT070TN82 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN83 V.3 | Innolux | 7.0 | 800×480 |
| AT070TN84 | Innolux | 7.0 | 800×480 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
| AT070TN93 | Innolux | 7.0 | 800×480 |
| AT070TNA2 | Innolux | 7.0 | 1024×600 |
| AT070TN83 V.3 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| AT070TNA2 | Innolux | 7.0 | 1024×600 |
| CLAA070NC0DCT | CPT | 7.0 | 1024×600 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| LMS430HF11-003 | Samsung | 4.3 | 480×272 |
| LMS430HF19 | Samsung | 4.3 | 480×272 |
| LMS700JF01-001 | Samsung | 7.0 | 1024×600 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
