| भाग नम्बर | G104SN03 V5 |
| ब्रान्ड | AUO |
| साइज | 10.4 |
| आवेदन | IA |
| संकल्प | 800×600 |
| रचना | LCM |
| चमक | 230 |
| CR | 500:1 |
| रंगहरू | 262K/16.2M |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | AUO |
| प्यानल मोडेल | G104SN03 V5 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 10.4 inch |
| संकल्प | 800(RGB)×600 , SVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 211.2×158.4 mm |
| रूपरेखा | 236×176.9×6 mm |
| सतह | Antiglare, Hard coating (3H) |
| चमक | 230 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| प्रतिक्रिया समय | 10/5 (Typ.)(Tr/Td) |
| हेर्ने कोण | 80/80/60/70 (Typ.)(CR=10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 3 stringsWLEDEmbedded (LED Driver) |
| संकेत इन्टरफेस | LVDS (1 ch, 6/8-bit), 20 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | IA |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G104SN02 V0 | AUO | 10.4 | 800×600 |
| G104SN02 V1 | AUO | 10.4 | 800×600 |
| G104SN02 V2 | AUO | 10.4 | 800×600 |
| G104SN03 V0 | AUO | 10.4 | 800×600 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| G104SN03 V4 | AUO | 10.4 | 800×600 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
| AA121TD01-DE3 | Mitsubishi | 12.1 | 1280×800 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| DMF5005NYJ-LY | Kyocera | 5.2 | 240×64 |
| EW24B00GLY | EDT | 5.2 | 240×64 |
| LB170E01-SL01 | LG Display | 17.0 | 1280×1024 |
| LM10V332R | SHARP | 10.4 | 640×480 |
| LQ057Q3DC03 | SHARP | 5.7 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| TX26D05VM1CAA | KOE | 10.4 | 640×480 |
