| भाग नम्बर | G121SN01 V3 |
| ब्रान्ड | AUO |
| साइज | 12.1 |
| आवेदन | IA |
| संकल्प | 800×600 |
| रचना | LCM |
| चमक | 400 |
| CR | 600:1 |
| रंगहरू | 262K/16.2M |
| ब्याकलाइट | CCFL |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | AUO |
| प्यानल मोडेल | G121SN01 V3 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 12.1 inch |
| संकल्प | 800(RGB)×600 , SVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 246×184.5 mm |
| रूपरेखा | 279×209×11 mm |
| सतह | Antiglare, Hard coating (3H) |
| चमक | 400 cd/m² (Typ.) |
| विपरीत अनुपात | 600:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.2M (6-bit / 6-bit + FRC), CIE193155% |
| प्रतिक्रिया समय | 10/25 (Typ.)(Tr/Td) |
| हेर्ने कोण | 80/80/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 2 pcsCCFLWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 6/8-bit), 20 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | IA |
