| भाग नम्बर | G121XTN01.0 |
| ब्रान्ड | AUO |
| साइज | 12.1 |
| आवेदन | IA |
| संकल्प | 1024×768 |
| रचना | LCM |
| चमक | 500 |
| CR | 700:1 |
| रंगहरू | 262K/16.2M |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | AUO |
| प्यानल मोडेल | G121XTN01.0 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 12.1 inch |
| संकल्प | 1024(2)×768(2) , XGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 245.76×184.32 mm |
| रूपरेखा | 279×209×9 mm |
| सतह | Antiglare, Hard coating (3H) |
| चमक | 500 cd/m² (Typ.) |
| विपरीत अनुपात | 700:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.2M (6-bit / 6-bit + FRC), CIE193172% |
| प्रतिक्रिया समय | 25/10 (Typ.)(Tr/Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 6S3PWLEDEmbedded (LED Driver) |
| संकेत इन्टरफेस | LVDS (1 ch, 6/8-bit), 20 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | IA |
