| भाग नम्बर | H466TAN01.0 |
| ब्रान्ड | AUO |
| साइज | 4.7 |
| आवेदन | MPH |
| संकल्प | 720×1280 |
| रचना | LCM |
| चमक | 400 |
| CR | 900:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | AUO |
| प्यानल मोडेल | H466TAN01.0 |
| प्यानल प्रकार | LTPS TFT-LCD , LCM |
| प्यानल आकार | 4.7 inch |
| संकल्प | 720(RGB)×1280 , WXGA |
| प्रदर्शन मोड | AHVA, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 58.104×103.296 mm |
| रूपरेखा | 61.92×114.38×1.75 mm |
| सतह | |
| चमक | 400 cd/m² (Typ.) |
| विपरीत अनुपात | 900:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193170% |
| प्रतिक्रिया समय | 35 (Max.)(Tr+Td) |
| हेर्ने कोण | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | WLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (3 data lanes), 25 pins |
| आवेदन | MPH |
