| भाग नम्बर | IROP018-010-0128064-W |
| ब्रान्ड | Other |
| साइज | 0.96 |
| आवेदन | MPH |
| संकल्प | 128×64 |
| रचना | OLED |
| चमक | 100 |
| CR | 2000:1 |
| रंगहरू | Mono(White) |
| ब्याकलाइट | self |
| इन्टरफेस | CPU/SPI/I²C |
| प्यानल ब्रान्ड | IRICO |
| प्यानल मोडेल | IROP018-010-0128064-W |
| प्यानल प्रकार | PM-OLED , OLED |
| प्यानल आकार | 0.96 inch |
| संकल्प | 128×64 |
| सक्रिय क्षेत्र | 21.74×10.86 mm |
| रूपरेखा | 26.4×19.7×1.36 mm |
| सतह | Antiglare |
| चमक | 100 cd/m² (Typ.) |
| विपरीत अनुपात | 2000 : 1 (Min.) |
| प्रदर्शन रंगहरू | Mono(White) (1-bit) |
| हेर्ने कोण | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| चालक आईसी | COG Built-in SEPS200A |
| संकेत इन्टरफेस | 8-bit 6800/8080 parallel, SPI, I²C, 31 pins |
| इनपुट भोल्टेज | 2.8/12.0V (Typ.)(VDD/VCC) |
| आवेदन | MPH |
| IROP018-010-0128064-W | Other | 0.96 | 128×64 |
| L3P10Y-81G00 | Epson | 0.96 | 1400×1050 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-G-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| RGS10128064WR010 | RiTdisplay | 0.96 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
| 43WVF3A | SII | 4.3 | 480×800 |
| AMFN888 | Samsung | 3.1 | 480×800 |
| AMS427GL45-0 | Samsung | 4.3 | 480×800 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| LH600WF2-SD01 | LG Display | 6.0 | 1080×1920 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS030Y7PW01 | SHARP | 3.0 | |
| LS038Y3LX01 | SHARP | 3.8 | 480×800 |
| OEL9M0039-R-E | Other | 1.5 | 128×128 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
