| भाग नम्बर | LH530QH1-SD01 |
| ब्रान्ड | LG Display |
| साइज | 5.3 |
| आवेदन | MPH |
| संकल्प | 1440×2560 |
| रचना | Assembly |
| चमक | 500 |
| CR | 1500:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | LG Display |
| प्यानल मोडेल | LH530QH1-SD01 |
| प्यानल प्रकार | LTPS TFT-LCD , Assembly |
| प्यानल आकार | 5.3 inch |
| संकल्प | 1440(RGB)×2560 , Quad-HD |
| सक्रिय क्षेत्र | 65.88×117.12 mm |
| रूपरेखा | 70.3×135.19×1.86 mm |
| सतह | Hard coating |
| चमक | 500 cd/m² (Typ.) |
| विपरीत अनुपात | 1500:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193185% |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| संकेत इन्टरफेस | MIPI (2 ch, 4 data lanes), 54 pins |
| इनपुट भोल्टेज | 1.8/3.3/5.4/-5.4V (Typ.)(VDDI/VPNL/DDVDH/DDVDL) |
| आवेदन | MPH |
| AMS529BY01 | Samsung | 5.3 | 1080×1920 |
| AMS529HA01 | Samsung | 5.3 | 800×1280 |
| CLAN053WA31 2AX | CPT | 5.3 | 720×1280 |
| DMF6104NF-FW | Kyocera | 5.3 | 256×128 |
| EG4401S-ER | Epson | 5.3 | 256×128 |
| EG4401S-FR-1 | Epson | 5.3 | 256×128 |
| LH530QH1-SD01 | LG Display | 5.3 | 1440×2560 |
| LH530WX1-SH02 | LG Display | 5.3 | 720×1280 |
| AMS410GC01-0 | Samsung | 4.1 | 480×800 |
| CLAF055LA41 TXX | CPT | 5.5 | 540×960 |
| H429AL02.0 | AUO | 4.3 | 540×960 |
| L5F30774P01 | Epson | 2.6 | 240×320 |
| LH300WQ1-ED01 | LG Display | 3.0 | 240×400 |
| LH400WV3-SD04 | LG Display | 4.0 | 480×800 |
| LS050T1SX04 | SHARP | 5.0 | 1080×1920 |
| LS063R1SX01 | SHARP | 6.3 | 1440×2560 |
| OEL9M0039-G-E | Other | 1.5 | 128×128 |
| PJ045IC-01F | Innolux | 4.5 | 720×1280 |
