| भाग नम्बर | LQ035Q7DH05 |
| ब्रान्ड | SHARP |
| साइज | 3.5 |
| आवेदन | PDA |
| संकल्प | 240×320 |
| रचना | LCM |
| चमक | 110 |
| CR | 95:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | TTL |
| प्यानल ब्रान्ड | SHARP |
| प्यानल मोडेल | LQ035Q7DH05 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 3.5 inch |
| संकल्प | 240(RGB)×320 , QVGA |
| प्रदर्शन मोड | TN, Normally White, Transflective |
| सक्रिय क्षेत्र | 53.64×71.52 mm |
| रूपरेखा | 65×86.2×4.2 mm |
| सतह | Hard coating (3H) |
| चमक | 110 cd/m² (Typ.) |
| विपरीत अनुपात | 95:1 (Typ.)(Transmissive)3:1 (Typ.)(Reflective) |
| प्रदर्शन रंगहरू | 262K (6-bit), CIE193129% |
| प्रतिक्रिया समय | 15/30 (Typ.)(Tr/Td) |
| हेर्ने कोण | 50/50/50/50 (Typ.)(CR≥2)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | WLEDWithout Driver |
| संकेत इन्टरफेस | Parallel RGB (1 ch, 6-bit), 61 pins |
| इनपुट भोल्टेज | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| आवेदन | PDA |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LQ035LC111 | Innolux | 3.5 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LQ035Q1DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q1DH01 | SHARP | 3.5 | 320×240 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB04 | SHARP | 3.5 | 240×320 |
| LQ035Q7DB05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH06 | SHARP | 3.5 | 240×320 |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| LTM035A776B | TOSHIBA | 3.5 | 240×320 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| NL2432HC22-50B | NLT | 3.5 | 240×320 |
| TD035STED7 | TPO | 3.5 | 240×320 |
