| भाग नम्बर | LS030Y3DX01 |
| ब्रान्ड | SHARP |
| साइज | 3.0 |
| आवेदन | MPH |
| संकल्प | 480×800 |
| रचना | LCM |
| चमक | 500 |
| CR | 500:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | TTL |
| प्यानल ब्रान्ड | SHARP |
| प्यानल मोडेल | LS030Y3DX01 |
| प्यानल प्रकार | CG-Silicon , LCM |
| प्यानल आकार | 3.0 inch |
| संकल्प | 480(RGB)×800 , WVGA |
| प्रदर्शन मोड | ASV, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 38.88×64.8 mm |
| रूपरेखा | 45.6×76.4 mm |
| सतह | |
| चमक | 500 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193175% |
| प्रतिक्रिया समय | 11/24 (Typ.)(Tr/Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 1S6PWLEDWithout Driver |
| संकेत इन्टरफेस | Parallel RGB (1 ch, 8-bit) + SPI, 49 pins |
| इनपुट भोल्टेज | 2.8/2.8V (Typ.)(VDDIO/VCC) |
| आवेदन | MPH |
