| भाग नम्बर | LTN070NL01 |
| ब्रान्ड | Samsung |
| साइज | 7.0 |
| आवेदन | PAD |
| संकल्प | 1024×600 |
| रचना | LCM |
| चमक | 400 |
| CR | 800:1 |
| रंगहरू | 16.2M |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | SAMSUNG |
| प्यानल मोडेल | LTN070NL01 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 7.0 inch |
| संकल्प | 1024(RGB)×600 , WSVGA |
| प्रदर्शन मोड | PLS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 153.6×90 mm |
| रूपरेखा | 164.05×100.86 mm |
| सतह | Glare (Haze 0%), Hard coating (3H) |
| चमक | 400 cd/m² (Typ.) |
| विपरीत अनुपात | 800:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.2M (6-bit + FRC), CIE193150% |
| प्रतिक्रिया समय | 30 (Typ.)(Tr+Td) |
| हेर्ने कोण | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 6S4PWLEDEmbedded (LED Driver) |
| संकेत इन्टरफेस | LVDS (1 ch, 8-bit), 31 pins |
| इनपुट भोल्टेज | 3.7V (Typ.) |
| आवेदन | PAD |
