| भाग नम्बर | LTN133AT09-G02 |
| ब्रान्ड | Samsung |
| साइज | 13.3 |
| आवेदन | NBPC |
| संकल्प | 1280×800 |
| रचना | LCM |
| चमक | 275 |
| CR | 700:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | SAMSUNG |
| प्यानल मोडेल | LTN133AT09-G02 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 13.3 inch |
| संकल्प | 1280(RGB)×800 , WXGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 286.08×178.8 mm |
| रूपरेखा | 297.15×192.15×3.68 mm |
| आकार शैली | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| सतह | Glare (Haze 0%), Hard coating (3H) |
| चमक | 275 cd/m² (Typ.) |
| विपरीत अनुपात | 700:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K (6-bit), CIE193145% |
| प्रतिक्रिया समय | 16 (Typ.)(Tr+Td) |
| हेर्ने कोण | 70/70/55/60 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 9S6PWLEDWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 6-bit), 30 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | NBPC |
