| भाग नम्बर | N080ICE-GB1 |
| ब्रान्ड | Innolux |
| साइज | 8.0 |
| आवेदन | PAD |
| संकल्प | 800×1280 |
| रचना | LCM |
| चमक | 350 |
| CR | 800:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | INNOLUX |
| प्यानल मोडेल | N080ICE-GB1 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 8.0 inch |
| संकल्प | 800(RGB)×1280 , WXGA |
| प्रदर्शन मोड | AAS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 107.64×172.224 mm |
| रूपरेखा | 120.65×187.64×5.1 mm |
| सतह | Hard coating (3H), Antireflection |
| चमक | 350 cd/m² (Typ.) |
| विपरीत अनुपात | 800:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193160% |
| प्रतिक्रिया समय | 25 (Typ.)(Tr+Tf) |
| हेर्ने कोण | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | WLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (4 data lanes), 31 pins |
| इनपुट भोल्टेज | 1.8/3.6V (Typ.)(VDD/VCI) |
| आवेदन | PAD |
| B080EAN02.2 | AUO | 8.0 | 800×1280 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| LSL080AL02-B01 | Samsung | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C2 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB1 | Innolux | 8.0 | 800×1280 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| CLAA070NQ01 XN | CPT | 7.0 | 1024×600 |
| CLAP070WP03XG | CPT | 7.0 | 800×1280 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| HV121WX5-110 | HYDIS | 12.1 | 1280×800 |
| LD070WX6-SM01 | LG Display | 7.0 | 800×1280 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
