| भाग नम्बर | N101ICE-G62 |
| ब्रान्ड | Innolux |
| साइज | 10.1 |
| आवेदन | PAD |
| संकल्प | 1280×800 |
| रचना | LCM |
| चमक | 350 |
| CR | 800:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | INNOLUX |
| प्यानल मोडेल | N101ICE-G62 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 10.1 inch |
| संकल्प | 1280(RGB)×800 , WXGA |
| प्रदर्शन मोड | AAS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 216.96×135.6 mm |
| रूपरेखा | 228.6×149.2×4.6 mm |
| सतह | Glare (Haze 0%), Hard coating (3H) |
| चमक | 350 cd/m² (Typ.) |
| विपरीत अनुपात | 800:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193150% |
| प्रतिक्रिया समय | 10/15 (Typ.)(Tr/Td) |
| हेर्ने कोण | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 6 stringsWLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (4 data lanes), 39 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | PAD |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| LTN101NT05-U03 | Samsung | 10.1 | 1024×600 |
| N101ICE-G62 | Innolux | 10.1 | 1280×800 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.A1 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP094WX1-SLA1 | LG Display | 9.4 | 1280×800 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LQ101R1SX03 | SHARP | 10.1 | 2560×1600 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
