| भाग नम्बर | N133I7-L01 |
| ब्रान्ड | Innolux |
| साइज | 13.3 |
| आवेदन | NBPC |
| संकल्प | 1280×800 |
| रचना | LCM |
| चमक | 250 |
| CR | 500:1 |
| रंगहरू | 262K |
| ब्याकलाइट | CCFL |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | CMO |
| प्यानल मोडेल | N133I7-L01 1 Compatible model |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 13.3 inch |
| संकल्प | 1280(RGB)×800 , WXGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 286.08×178.8 mm |
| रूपरेखा | 299×195×5.5 mm |
| आकार शैली | Wedge (PCBA Bent, Depth ≥5.2mm) |
| सतह | Glare (Haze 0%), Hard coating (2H), Reflection 1.0% (Max.) |
| चमक | 250 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K (6-bit), CIE193148% |
| प्रतिक्रिया समय | 3/7 (Typ.)(Tr/Td) |
| हेर्ने कोण | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 1 pcsCCFLWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 6-bit), 20 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | NBPC |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP133X3-A | LG Display | 13.3 | 1024×768 |
| LT133EE09400 | TOSHIBA | 13.3 | 1366×768 |
| N133I1-L01 | Innolux | 13.3 | 1280×800 |
| N133I5-L01 | Innolux | 13.3 | 1280×800 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
| N133I6-L09 | Innolux | 13.3 | 1280×800 |
| N133I6-L10 | Innolux | 13.3 | 1280×800 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| NV133FHM-N52 | BOE | 13.3 | 1920×1080 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP140WD2-TLE2 | LG Display | 14.0 | 1600×900 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| LP171WX2-TLB1 | LG Display | 17.1 | 1440×900 |
| LTN141XB-L03 | Samsung | 14.1 | 1024×768 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
| N133I7-L01 | Innolux | 13.3 | 1280×800 |
| N140FGE-LA2 | Innolux | 14.0 | 1600×900 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
