| भाग नम्बर | PD035QX2 |
| ब्रान्ड | E Ink |
| साइज | 3.5 |
| आवेदन | DVC |
| संकल्प | 320×240 |
| रचना | LCM |
| चमक | 500 |
| CR | 500:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | Parallel/Serial |
| प्यानल ब्रान्ड | PVI |
| प्यानल मोडेल | PD035QX2 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 3.5 inch |
| संकल्प | 320(RGB)×240 , QVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 70.08×52.56 mm |
| रूपरेखा | 78.3×64.5×3.8 mm |
| सतह | Antiglare |
| चमक | 500 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K (6-bit) |
| प्रतिक्रिया समय | 15/25 (Typ.)(Tr/Td) |
| हेर्ने कोण | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| बत्ती प्रकार | 3S3PWLEDWithout Driver |
| संकेत इन्टरफेस | Digital RGB (8/24-bit) + SPI, CCIR601/656, 50 pins |
| इनपुट भोल्टेज | 3.3/3.3V (Typ.)(VDDA/VDD) |
| rohs: | |
| आवेदन | DVC |
| COM35H3M74UTC | ORTUSTECH | 3.5 | 480×640 |
| LTP350QV-E06 | Samsung | 3.5 | 240×320 |
| NL2432HC22-40J | NLT | 3.5 | 240×320 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| PD035OX4 | E Ink | 3.5 | 320×234 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| PD035VX2 | E Ink | 3.5 | 640×480 |
| PD035VX8 | E Ink | 3.5 | 480×640 |
| PD035VX9 | E Ink | 3.5 | 480×640 |
| 990000553 | TPO | 3.5 | 320×240 |
| A035CN02 V1 | AUO | 3.5 | 480×234 |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| COM48T4Mxxxxx | ORTUSTECH | 4.8 | 1920×1080 |
| LS032V8DY01 | SHARP | 3.2 | 640×480 |
| LTV280QV-F02 | Samsung | 2.8 | 320×240 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
