| भाग नम्बर | TCG035QVLPDANN-GN50 |
| ब्रान्ड | Kyocera |
| साइज | 3.5 |
| आवेदन | IA |
| संकल्प | 320×240 |
| रचना | LCM |
| चमक | 1000 |
| CR | 1000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | TTL |
| प्यानल ब्रान्ड | Kyocera |
| प्यानल मोडेल | TCG035QVLPDANN-GN50 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 3.5 inch |
| संकल्प | 320(RGB)×240 , QVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 70.56×52.92 mm |
| रूपरेखा | 76.9×63.9×5.1 mm |
| सतह | Glare (Haze 0%) |
| चमक | 1000 cd/m² (Typ.) |
| विपरीत अनुपात | 1000:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit) |
| प्रतिक्रिया समय | 8/22 (Typ.)(Tr/Td) |
| हेर्ने कोण | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 2 stringsWLEDWithout Driver |
| संकेत इन्टरफेस | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | IA |
