| भाग नम्बर | VVX10F011B00 |
| ब्रान्ड | Panasonic |
| साइज | 10.1 |
| आवेदन | PAD |
| संकल्प | 1920×1200 |
| रचना | LCM |
| चमक | 650 |
| CR | 1000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | eDP |
| प्यानल ब्रान्ड | Panasonic |
| प्यानल मोडेल | VVX10F011B00 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 10.1 inch |
| संकल्प | 1920(RGB)×1200 , WUXGA |
| प्रदर्शन मोड | IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 217.44×135.9 mm |
| रूपरेखा | 228.86×152.5×4.18 mm |
| सतह | Hard coating, Antireflection |
| चमक | 650 cd/m² (Min.) |
| विपरीत अनुपात | 1000:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193150% |
| प्रतिक्रिया समय | 35 (Max.)(Tr+Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 10S6PWLEDEmbedded (LED Driver) |
| संकेत इन्टरफेस | eDP (2 Lanes), 30 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | PAD |
