| भाग नम्बर | AT070TN83 |
| ब्रान्ड | Innolux |
| साइज | 7.0 |
| आवेदन | MP4 |
| संकल्प | 800×480 |
| रचना | LCM |
| चमक | 300 |
| CR | 500:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | TTL |
| प्यानल ब्रान्ड | INNOLUX |
| प्यानल मोडेल | AT070TN83 0 Compatible model |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 7.0 inch |
| संकल्प | 800(RGB)×480 , WVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 152.4×91.44 mm |
| रूपरेखा | 165×104×5.8 mm |
| सतह | Antiglare |
| चमक | 300 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K (6-bit) |
| प्रतिक्रिया समय | 10/15 (Typ.)(Tr/Td) |
| हेर्ने कोण | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| बत्ती प्रकार | 3S9PWLEDWithout Driver |
| संकेत इन्टरफेस | TTL (1 ch, 6-bit), 40 pins |
| इनपुट भोल्टेज | 3.3V (Typ.)(VCC) |
| आवेदन | MP4 |
| AT070TN07 V.A | Innolux | 7.0 | 480×234 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| AT070TN82 | Innolux | 7.0 | 800×480 |
| AT070TN83 TP | Innolux | 7.0 | 800×480 |
| AT070TN83 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN83 V.3 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
| AT070TN93 V.2 | Innolux | 7.0 | 800×480 |
| AT070TN94 | Innolux | 7.0 | 800×480 |
| AT070TN83 TP | Innolux | 7.0 | 800×480 |
| AT070TN92 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070ND26CW | CPT | 7.0 | 1024×600 |
| CLAA070NQ02 XN | CPT | 7.0 | 1024×600 |
| DLC0700JMG-6 | Other | 7.0 | 1024×600 |
| HJ070NA-01U | Innolux | 7.0 | 1024×600 |
| LMS430HF11-003 | Samsung | 4.3 | 480×272 |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
