| भाग नम्बर | CLAA101FP05 XG |
| ब्रान्ड | CPT |
| साइज | 10.1 |
| आवेदन | PAD |
| संकल्प | 1920×1200 |
| रचना | LCM |
| चमक | 370 |
| CR | 800:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | CPT |
| प्यानल मोडेल | CLAA101FP05 XG |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 10.1 inch |
| संकल्प | 1920(RGB)×1200 , WUXGA |
| प्रदर्शन मोड | HFFS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 216.576×135.36 mm |
| रूपरेखा | 227.72×148.65×4.55 mm |
| सतह | Glare (Haze 0%), Hard coating |
| चमक | 370 cd/m² (Typ.) |
| विपरीत अनुपात | 800:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (6-bit + Hi-FRC), CIE193150% |
| प्रतिक्रिया समय | 30 (Typ.)(Tr+Td) |
| हेर्ने कोण | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 5S6PWLEDEmbedded (LED Driver) |
| संकेत इन्टरफेस | MIPI (4 data lanes), 34 pins |
| इनपुट भोल्टेज | 3.7V (Typ.) |
| आवेदन | PAD |
