| भाग नम्बर | COM35H3P09UTC |
| ब्रान्ड | ORTUSTECH |
| साइज | 3.5 |
| आवेदन | HHP |
| संकल्प | 480×640 |
| रचना | LCM |
| चमक | 200 |
| CR | 600:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | TTL |
| प्यानल ब्रान्ड | ORTUSTECH |
| प्यानल मोडेल | COM35H3P09UTC 1 Compatible model |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 3.5 inch |
| संकल्प | 480(RGB)×640 , VGA |
| प्रदर्शन मोड | Buenaview, Normally Black, Transflective |
| सक्रिय क्षेत्र | 53.28×71.04 mm |
| रूपरेखा | 63.5×85×5.83 mm |
| सतह | Hard coating (3H) |
| चमक | 200 cd/m² (Typ.) |
| विपरीत अनुपात | 600:1 (Typ.)(Transmissive)5.5:1 (Typ.)(Reflective) |
| प्रदर्शन रंगहरू | 262K (6-bit) |
| प्रतिक्रिया समय | 40/60 (Max.)(Tr/Td) |
| हेर्ने कोण | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 6S1PWLEDWithout Driver |
| संकेत इन्टरफेस | Parallel RGB (1 ch, 6-bit), 39 pins |
| इनपुट भोल्टेज | 3.0/1.8V (Typ.)(VDD/VCCIO) |
| आवेदन | HHP |
