| भाग नम्बर | CT035TN02 |
| ब्रान्ड | Innolux |
| साइज | 3.5 |
| आवेदन | MPH |
| संकल्प | 320×480 |
| रचना | LCM |
| चमक | 320 |
| CR | 500:1 |
| रंगहरू | 65K/262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | CPU/RGB/SPI |
| प्यानल ब्रान्ड | CHIMEI INNOLUX |
| प्यानल मोडेल | CT035TN02 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 3.5 inch |
| संकल्प | 320(RGB)×480 , HVGA |
| प्रदर्शन मोड | IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 48.96×73.44 mm |
| रूपरेखा | 54.76×85.24×2.1 mm |
| सतह | |
| चमक | 320 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 65K/262K , CIE193170% |
| प्रतिक्रिया समय | 30 (Typ.)(Tr+Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 1S5PWLEDWithout Driver |
| संकेत इन्टरफेस | CPU/RGB/SPI, 50 pins |
| इनपुट भोल्टेज | 2.8/2.8V (Typ.)(VDD3/VCI) |
| आवेदन | MPH |
