| भाग नम्बर | EL320.240.36 HB SE |
| ब्रान्ड | PLANAR |
| साइज | 5.7 |
| आवेदन | IA |
| संकल्प | 320×240 |
| रचना | EL |
| चमक | 150 |
| CR | 90:1 |
| रंगहरू | Mono(Yellow) |
| ब्याकलाइट | self |
| इन्टरफेस | Parallel Data |
| प्यानल ब्रान्ड | PLANAR |
| प्यानल मोडेल | EL320.240.36 HB SE |
| प्यानल प्रकार | EL , EL |
| प्यानल आकार | 5.7 inch |
| संकल्प | 320×240 , QVGA |
| सक्रिय क्षेत्र | 115.1×86.3 mm |
| रूपरेखा | 148.1×104.7 mm |
| सतह | |
| चमक | 150 cd/m² (Typ.) |
| विपरीत अनुपात | 90 : 1 (Typ.) |
| प्रदर्शन रंगहरू | Mono(Yellow) (1-bit) |
| हेर्ने कोण | 89/89/89/89 (Typ.)(L/R/U/D) |
| आवृत्ति | 120Hz |
| संकेत इन्टरफेस | Parallel Data (1ch, 4-bit), 26 pins |
| इनपुट भोल्टेज | 5/12V (Typ.)(VL/VH) |
| आवेदन | IA |
| EL320.240-FA3 CC | Lumineq | 4.9 | 320×240 |
| EL320.240.36 | Lumineq | 5.7 | 320×240 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| EL320.240.36 HB NE | PLANAR | 5.7 | 320×240 |
| EL320.240.36 HB NE CC | PLANAR | 5.7 | 320×240 |
| EL320.240.36 HB SE | PLANAR | 5.7 | 320×240 |
| EL320.240.36 IN | Lumineq | 5.7 | 320×240 |
| EL320.240.36 IN AG | Lumineq | 5.7 | 320×240 |
| EL320.240.36 LK | Lumineq | 5.7 | 320×240 |
| EL160.80.50 ALU | PLANAR | 3.5 | 160×80 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| G150XGE-L06 | Innolux | 15.0 | 1024×768 |
| KCG057QV1DB-G500 | Kyocera | 5.7 | 320×240 |
| LJ640U21 | SHARP | 7.9 | 640×200 |
| LJ64H034 | SHARP | 8.9 | 640×400 |
| LT084AC27900 | TOSHIBA | 8.4 | 800×600 |
| M070SWP1 R4 | IVO | 7.0 | 800×480 |
| TX26D12VM0APA | KOE | 10.4 | 800×600 |
| TX26D203VM2BAA | KOE | 10.4 | 1024×768 |
