| भाग नम्बर | H546DLB01.1 |
| ब्रान्ड | AUO |
| साइज | 5.5 |
| आवेदन | MPH |
| संकल्प | 1080×1920 |
| रचना | OLED |
| चमक | 350 |
| CR | 10000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | self |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | AUO |
| प्यानल मोडेल | H546DLB01.1 |
| प्यानल प्रकार | AM-OLED , OLED |
| प्यानल आकार | 5.5 inch |
| संकल्प | 1080(RGB)×1920 , FHD |
| सक्रिय क्षेत्र | 68.04×120.96 mm |
| रूपरेखा | 70.84×128.01 mm |
| सतह | Hard coating (3H) |
| चमक | 350 cd/m² (Typ.) |
| विपरीत अनुपात | 10000 : 1 (Min.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE1931103% |
| हेर्ने कोण | 80/80/80/80 (Min.)(CR≥1600)(L/R/U/D) |
| चालक आईसी | COG Built-in RM69070 |
| संकेत इन्टरफेस | MIPI (2 data lanes), 40 pins |
| इनपुट भोल्टेज | 1.8/3.0/4.6/7.6V (Typ.)(IOVCC/VCI/OVDD/AVDD) |
| आवेदन | MPH |
