| भाग नम्बर | LH550WF4-SD01 |
| ब्रान्ड | LG Display |
| साइज | 5.5 |
| आवेदन | MPH |
| संकल्प | 1080×1920 |
| रचना | Assembly |
| चमक | 550 |
| CR | 1600:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | LG Display |
| प्यानल मोडेल | LH550WF4-SD01 |
| प्यानल प्रकार | LTPS TFT-LCD , Assembly |
| प्यानल आकार | 5.5 inch |
| संकल्प | 1080(RGB)×1920 , FHD |
| सक्रिय क्षेत्र | 68.364×121.536 mm |
| रूपरेखा | 75.27×155.55×2.35 mm |
| सतह | |
| चमक | 550 cd/m² (Typ.) |
| विपरीत अनुपात | 1600:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193170% |
| हेर्ने कोण | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| संकेत इन्टरफेस | MIPI (4 data lanes), 36 pins |
| इनपुट भोल्टेज | 1.8//5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
| आवेदन | MPH |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LH550WF2-SD01 | LG Display | 5.5 | 1080×1920 |
| LH550WF2-SD03 | LG Display | 5.5 | 1080×1920 |
| LH550WF4-SD01 | LG Display | 5.5 | 1080×1920 |
| LH550WF4-SJ11 | LG Display | 5.5 | 1080×1920 |
| LPM055A138A | JDI | 5.5 | 1440×2560 |
| LS055T3SX05 | SHARP | 5.5 | 1080×1920 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
| UG-5664ASGGF01 | WiseChip | 5.5 | 256×64 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| H361VL01 V4 | AUO | 3.6 | 480×800 |
| HSD015F4N2-B | HannStar | 1.5 | 128×128 |
| LH240Q29-SH04 | LG Display | 2.4 | 240×320 |
| LH350H01-FD01-A41 | LG Display | 3.5 | 320×480 |
| LH430WV3-SH02 | LG Display | 4.3 | 480×800 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
| TP241MC01G | Neoview Kolon | 2.4 | 240×320 |
