| भाग नम्बर | HJ080IA-01B |
| ब्रान्ड | Innolux |
| साइज | 8.0 |
| आवेदन | PAD |
| संकल्प | 1024×768 |
| रचना | LCM |
| चमक | 350 |
| CR | 800:1 |
| रंगहरू | 262K/16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | CHIMEI INNOLUX |
| प्यानल मोडेल | HJ080IA-01B |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 8.0 inch |
| संकल्प | 1024(RGB)×768 , XGA |
| प्रदर्शन मोड | IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 162.048×121.536 mm |
| रूपरेखा | 174×136×2.9 mm |
| सतह | Hard coating |
| चमक | 350 cd/m² (Typ.) |
| विपरीत अनुपात | 800:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| प्रतिक्रिया समय | 25 (Typ.)(Tr+Td) |
| हेर्ने कोण | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 3S11PWLEDWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 6/8-bit), 40 pins |
| इनपुट भोल्टेज | 3.3/10.0/18.9/-7.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| आवेदन | PAD |
| A080SN02 V0 | AUO | 8.0 | 800×600 |
| AV080WSM-NW3 | BOE | 8.0 | 1024×600 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080XA01BW | CPT | 8.0 | 1024×768 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| HJ080IA-01B | Innolux | 8.0 | 1024×768 |
| HJ080IA-01E | Innolux | 8.0 | 1024×768 |
| HJ080IA-01F | Innolux | 8.0 | 1024×768 |
| HJ080NA-04L | Innolux | 8.0 | 1024×768 |
| LM64C219 | SHARP | 8.0 | 640×480 |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| LTL070NL02-W02 | Samsung | 7.0 | 1024×600 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| N080JCE-G41 | Innolux | 8.0 | 1200×1920 |
| PJ101IA-01A | Innolux | 10.1 | 1280×800 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
