| भाग नम्बर | LH550WF2-SD03 |
| ब्रान्ड | LG Display |
| साइज | 5.5 |
| आवेदन | MPH |
| संकल्प | 1080×1920 |
| रचना | LCM |
| चमक | 460 |
| CR | 1000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | LG Display |
| प्यानल मोडेल | LH550WF2-SD03 |
| प्यानल प्रकार | LTPS TFT-LCD , LCM |
| प्यानल आकार | 5.5 inch |
| संकल्प | 1080(RGB)×1920 , FHD |
| प्रदर्शन मोड | AH3-IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 68.04×120.96 mm |
| रूपरेखा | 70.94×128.01×1.55 mm |
| सतह | |
| चमक | 460 cd/m² (Typ.) |
| विपरीत अनुपात | 1000:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193170% |
| प्रतिक्रिया समय | 25 (Typ.)(Tr+Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 6S2PWLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (4 data lanes), 50 pins |
| इनपुट भोल्टेज | 1.8/5.0/-5.0V (Typ.)(VDD/VAN/VPG) |
| आवेदन | MPH |
