| भाग नम्बर | N070ICN-GB1 |
| ब्रान्ड | Innolux |
| साइज | 7.0 |
| आवेदन | PAD |
| संकल्प | 800×1280 |
| रचना | LCM |
| चमक | 300 |
| CR | 800:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | INNOLUX |
| प्यानल मोडेल | N070ICN-GB1 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 7.0 inch |
| संकल्प | 800(RGB)×1280 , WXGA |
| प्रदर्शन मोड | IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 94.2×150.72 mm |
| रूपरेखा | 105.62×163.27×4.56 mm |
| सतह | Glare (Haze 0%), Hard coating (3H) |
| चमक | 300 cd/m² (Typ.) |
| विपरीत अनुपात | 800:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193160% |
| प्रतिक्रिया समय | 11/9 (Typ.)(Tr/Td) |
| हेर्ने कोण | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 3S6PWLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (4 data lanes), 31 pins |
| इनपुट भोल्टेज | 1.8/3.3V (Typ.)(VDDI/VCI) |
| आवेदन | PAD |
