| भाग नम्बर | N070ICE-GB1 |
| ब्रान्ड | Innolux |
| साइज | 7.0 |
| आवेदन | PAD |
| संकल्प | 800×1280 |
| रचना | LCM |
| चमक | 300 |
| CR | 1000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | INNOLUX |
| प्यानल मोडेल | N070ICE-GB1 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 7.0 inch |
| संकल्प | 800(RGB)×1280 , WXGA |
| प्रदर्शन मोड | IPS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 94.2×150.72 mm |
| रूपरेखा | 105.62×163.27×3.95 mm |
| सतह | Glare (Haze 0%), Hard coating (3H) |
| चमक | 300 cd/m² (Typ.) |
| विपरीत अनुपात | 1000:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit) |
| प्रतिक्रिया समय | 14/11 (Typ.)(Tr/Td) |
| हेर्ने कोण | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 3S6PWLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (4 data lanes), 36 pins |
| इनपुट भोल्टेज | 1.8/3.3V (Typ.)(VCC/VDD) |
| आवेदन | PAD |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| N070ICG-LD1 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| N070ICG-LD4 | Innolux | 7.0 | 1280×800 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| TR-LM7WR3PS | Panasonic | 7.0 | 480×234 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| LP097QX1-SPA2 | LG Display | 9.7 | 2048×1536 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
