| भाग नम्बर | NL10276AC28-05R |
| ब्रान्ड | NLT |
| साइज | 14.1 |
| आवेदन | DMPC |
| संकल्प | 1024×768 |
| रचना | LCM |
| चमक | 220 |
| CR | 150:1 |
| रंगहरू | 262K |
| ब्याकलाइट | CCFL |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | NEC |
| प्यानल मोडेल | NL10276AC28-05R |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 14.1 inch |
| संकल्प | 1024(RGB)×768 , XGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 285.696×214.272 mm |
| रूपरेखा | 330×255×20.5 mm |
| सतह | Antiglare, Hard coating (3H) |
| चमक | 220 cd/m² (Typ.) |
| विपरीत अनुपात | 150:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K (6-bit), CIE193140% |
| प्रतिक्रिया समय | 11/40 (Typ.)(Tr/Td) |
| हेर्ने कोण | 50/50/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| बत्ती प्रकार | 2 pcsCCFLEmbedded (Inverter) |
| संकेत इन्टरफेस | LVDS (1 ch, 6-bit), 20 pins |
| इनपुट भोल्टेज | 5.0V (Typ.) |
| आवेदन | DMPC |
