| भाग नम्बर | NL12876AC39-01 |
| ब्रान्ड | NLT |
| साइज | 23.0 |
| आवेदन | DMPC |
| संकल्प | 1280×768 |
| रचना | LCM |
| चमक | 450 |
| CR | 350:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | CCFL |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | NEC |
| प्यानल मोडेल | NL12876AC39-01 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 23.0 inch |
| संकल्प | 1280(RGB)×768 , WXGA |
| प्रदर्शन मोड | UA-SFT, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 501.12×300.672 mm |
| रूपरेखा | 528×326 mm |
| सतह | Hard coating (2H), Antireflection |
| चमक | 450 cd/m² (Typ.) |
| विपरीत अनुपात | 350:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193172% |
| प्रतिक्रिया समय | 10/13 (Typ.)(Tr/Td) |
| हेर्ने कोण | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 12 pcsCCFLEmbedded (Inverter) |
| संकेत इन्टरफेस | LVDS (1 ch, 8-bit), 20 pins |
| इनपुट भोल्टेज | 5.0V (Typ.) |
| आवेदन | DMPC |
