| भाग नम्बर | NL12876BC15-01 |
| ब्रान्ड | NLT |
| साइज | 8.9 |
| आवेदन | NBPC |
| संकल्प | 1280×768 |
| रचना | LCM |
| चमक | 280 |
| CR | 500:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | NEC |
| प्यानल मोडेल | NL12876BC15-01 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 8.9 inch |
| संकल्प | 1280(RGB)×768 , WXGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 193.92×116.352 mm |
| रूपरेखा | 209.2×130.3×7.7 mm |
| सतह | Clear, Hard coating (3H) |
| चमक | 280 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K (6-bit), CIE193156% |
| प्रतिक्रिया समय | 6/2 (Typ.)(Tr/Td) |
| हेर्ने कोण | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 11S3PWLEDWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 6-bit), 30 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | NBPC |
