| भाग नम्बर | OEL9M0039-W-E |
| ब्रान्ड | Other |
| साइज | 1.5 |
| आवेदन | MPH |
| संकल्प | 128×128 |
| रचना | OLED |
| चमक | 35 |
| CR | 10000:1 |
| रंगहरू | Grayscale(W) |
| ब्याकलाइट | self |
| इन्टरफेस | CPU/SPI |
| प्यानल ब्रान्ड | TRULY |
| प्यानल मोडेल | OEL9M0039-W-E |
| प्यानल प्रकार | PM-OLED , OLED |
| प्यानल आकार | 1.5 inch |
| संकल्प | 128×128 |
| सक्रिय क्षेत्र | 26.86×26.86 mm |
| रूपरेखा | 34.9×37.8×1.6 mm |
| सतह | |
| चमक | 35 cd/m² (Typ.) |
| विपरीत अनुपात | 10000 : 1 (Min.) |
| प्रदर्शन रंगहरू | Grayscale(W) (4-bit) |
| हेर्ने कोण | 80/80/80/80 (Min.)(L/R/U/D) |
| आवृत्ति | 100Hz |
| चालक आईसी | COG Built-in SSD1329Z |
| संकेत इन्टरफेस | 8-bit 6800/8080 parallel, SPI, 25 pins |
| इनपुट भोल्टेज | 3.0/3.0/15.0V (Typ.)(VDD/VDDIO/VCC) |
| आवेदन | MPH |
| OEL9M0039-B-E | Other | 1.5 | 128×128 |
| OEL9M0039-G-E | Other | 1.5 | 128×128 |
| OEL9M0039-W-E | Other | 1.5 | 128×128 |
| OEL9M0064-B-E | Other | 2.0 | 128×32 |
| OEL9M0064-Y-E | Other | 2.0 | 128×32 |
| OEL9M0072-B-E | Other | 1.54 | 128×64 |
| OEL9M0073-W-E | Other | 1.0 | 128×64 |
| OEL9M0073-Y-E | Other | 1.0 | 128×64 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-R-E | Other | 0.96 | 128×64 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| CT024TN04 V.F | Innolux | 2.4 | 240×320 |
| H495TAN01.1 | AUO | 5.0 | 720×1280 |
| LH350WS1-SD01 | LG Display | 3.5 | 640×960 |
| LH520WF1-SD01 | LG Display | 5.2 | 1080×1920 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| LS059T1SX01 | SHARP | 5.9 | 1080×1920 |
| LT044MDW7000 | TOSHIBA | 4.5 | 720×1280 |
| OEL9M0039-R-E | Other | 1.5 | 128×128 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
