| भाग नम्बर | TM027CDH04 |
| ब्रान्ड | Tianma |
| साइज | 2.7 |
| आवेदन | DSC |
| संकल्प | 320×240 |
| रचना | LCM |
| चमक | 300 |
| CR | 350:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | Serial RGB |
| प्यानल ब्रान्ड | TIANMA |
| प्यानल मोडेल | TM027CDH04 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 2.7 inch |
| संकल्प | 320(RGB)×240 , QVGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 54×40.5 mm |
| रूपरेखा | 63.5×46.6×2.8 mm |
| सतह | Clear, Hard coating (3H) |
| चमक | 300 cd/m² (Typ.) |
| विपरीत अनुपात | 350:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193140% |
| प्रतिक्रिया समय | 25/40 (Typ./Max.)(Tr+Td) |
| हेर्ने कोण | 50/50/25/55 (Typ.)(CR≥10)(L/R/U/D) |
| बत्ती प्रकार | 2S1PWLEDWithout Driver |
| संकेत इन्टरफेस | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | DSC |
