| भाग नम्बर | LS025A8DZ01S |
| ब्रान्ड | SHARP |
| साइज | 2.5 |
| आवेदन | DSC |
| संकल्प | 320×240 |
| रचना | LCM |
| चमक | 310 |
| CR | 400:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | Serial RGB |
| प्यानल ब्रान्ड | SHARP |
| प्यानल मोडेल | LS025A8DZ01S |
| प्यानल प्रकार | CG-Silicon , LCM |
| प्यानल आकार | 2.5 inch |
| संकल्प | 320(RGB)×240 , QVGA |
| प्रदर्शन मोड | ASV, Normally Black, Transflective |
| सक्रिय क्षेत्र | 49.9×37.4 mm |
| सतह | Hard coating (2H) |
| चमक | 310 cd/m² (Typ.) |
| विपरीत अनुपात | 400:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| प्रदर्शन रंगहरू | 16.7M (8-bit) |
| प्रतिक्रिया समय | 25/25 (Typ.)(Tr/Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | WLEDWithout Driver |
| संकेत इन्टरफेस | Serial RGB (8-bit), 45 pins |
| इनपुट भोल्टेज | 3.3V (Typ.)(VDD) |
| आवेदन | DSC |
