| भाग नम्बर | AT070TN01 |
| ब्रान्ड | Innolux |
| साइज | 7.0 |
| आवेदन | DPF |
| संकल्प | 480×234 |
| रचना | LCM |
| चमक | 350 |
| CR | 300:1 |
| रंगहरू | Full color |
| ब्याकलाइट | CCFL |
| इन्टरफेस | Analog |
| प्यानल ब्रान्ड | INNOLUX |
| प्यानल मोडेल | AT070TN01 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 7.0 inch |
| संकल्प | 480(RGB)×234 |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 154.08×86.58 mm |
| रूपरेखा | 164.9×100×6 mm |
| सतह | Antiglare |
| चमक | 350 cd/m² (Typ.) |
| विपरीत अनुपात | 300:1 (Typ.) |
| प्रदर्शन रंगहरू | Full color |
| प्रतिक्रिया समय | 15/20 (Typ.)(Tr/Td) |
| हेर्ने कोण | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 1 pcsCCFLWithout Driver |
| संकेत इन्टरफेस | TFT Specific Analog RGB, 26 pins |
| इनपुट भोल्टेज | 5.0/5.0/15.0/-10.0 (Typ.)(VCC/AVDD/VGH/VGL) |
| आवेदन | DPF |
