| भाग नम्बर | BT140GW02 V.0 |
| ब्रान्ड | Innolux |
| साइज | 14.0 |
| आवेदन | NBPC |
| संकल्प | 1366×768 |
| रचना | LCM |
| चमक | 220 |
| CR | 500:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | INNOLUX |
| प्यानल मोडेल | BT140GW02 V.0 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 14.0 inch |
| संकल्प | 1366(RGB)×768 , WXGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 309.399×173.952 mm |
| रूपरेखा | 323.5×192×5.2 mm |
| आकार शैली | Wedge (PCBA Bent, Depth ≥5.2mm) |
| सतह | Antiglare, Hard coating (3H) |
| चमक | 220 cd/m² (Typ.) |
| विपरीत अनुपात | 500:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K (6-bit), CIE193160% |
| प्रतिक्रिया समय | 8 (Typ.)(Tr+Td) |
| हेर्ने कोण | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | WLEDEmbedded (LED Driver) |
| संकेत इन्टरफेस | LVDS (1 ch, 6-bit), 40 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | NBPC |
| B140XW01 V9 | AUO | 14.0 | 1366×768 |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.4 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.5 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.A | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.2 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.9 | Innolux | 14.0 | 1366×768 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| N140BGE-L32 | Innolux | 14.0 | 1366×768 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B133XTN01.6 HW0A | AUO | 13.3 | 1366×768 |
| B140XTN02.4 | AUO | 14.0 | 1366×768 |
| HSD121PHW1-A03 | HannStar | 12.1 | 1366×768 |
| LP133WP1-TJAA | LG Display | 13.3 | 1440×900 |
| LQ164D1LA4B | SHARP | 16.4 | 1600×900 |
| LTD121LA3SG-201 | TOSHIBA | 12.1 | 1024×768 |
| LTN121AP03-001 | Samsung | 12.1 | 1280×800 |
| LTN154CT03-D01 | Samsung | 15.4 | 1920×1200 |
| N156B6-L07 | Innolux | 15.6 | 1366×768 |
