| भाग नम्बर | HSD050FMW2-D00 |
| ब्रान्ड | HannStar |
| साइज | 5.0 |
| आवेदन | MPH |
| संकल्प | 540×960 |
| रचना | CELL |
| चमक | 0 |
| CR | 700:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | No B/L |
| इन्टरफेस | |
| प्यानल ब्रान्ड | HannStar |
| प्यानल मोडेल | HSD050FMW2-D00 2 Compatible model |
| प्यानल प्रकार | a-Si TFT-LCD , CELL |
| प्यानल आकार | 5.0 inch |
| संकल्प | 540(RGB)×960 , qHD |
| प्रदर्शन मोड | IPS Pro, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 62.046×110.304 mm |
| रूपरेखा | 65.1×117.9×0.4 mm |
| सतह | Without Polarizer |
| गिलास गहिराई | 0.20+0.20 mm |
| प्रसारण क्षमता | 3.82% (Typ.)(with Polarizer) |
| विपरीत अनुपात | 700:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193172% |
| प्रतिक्रिया समय | 10/20 (Typ.)(Tr/Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| चालक आईसी | COG Suggest NT35516, NT35517, HX8389-B, RM68190, OTM9608A, OTM9605A |
| आवेदन | MPH |
