| भाग नम्बर | LS050T1SX06 |
| ब्रान्ड | SHARP |
| साइज | 5.0 |
| आवेदन | MPH |
| संकल्प | 1080×1920 |
| रचना | LCM |
| चमक | 480 |
| CR | 1000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | SHARP |
| प्यानल मोडेल | LS050T1SX06 |
| प्यानल प्रकार | CG-Silicon , LCM |
| प्यानल आकार | 5.0 inch |
| संकल्प | 1080(RGB)×1920 , FHD |
| प्रदर्शन मोड | New Mode2, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 61.884×110.016 mm |
| रूपरेखा | 64.3×116.6×1.5 mm |
| सतह | |
| चमक | 480 cd/m² (Typ.) |
| विपरीत अनुपात | 1000:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193171% |
| प्रतिक्रिया समय | 35 (Max.)(Tr+Td) |
| हेर्ने कोण | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 6S2PWLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (4 data lanes), 34 pins |
| इनपुट भोल्टेज | 1.8/5.0/-5.0V (Typ.)(IOVDD/VSP/VSN) |
| आवेदन | MPH |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| HSD050IDW1-A30 | HannStar | 5.0 | 800×480 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX04 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX06 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX12(K) | SHARP | 5.0 | 1080×1920 |
| LTE052T-4301-1 | TPO | 5.0 | 320×234 |
| PA050XU4 | E Ink | 5.0 | 320×234 |
| ACX435AKN-7 | SONY | 4.5 | 800×1280 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| H381DLN01.0 | AUO | 3.8 | 1080×1200 |
| H497TLB01 | AUO | 5.0 | 720×1280 |
| HSD050FMW2-D00 | HannStar | 5.0 | 540×960 |
| LH400WV3-SD04 | LG Display | 4.0 | 480×800 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
