| भाग नम्बर | LS050T1SX12(K) |
| ब्रान्ड | SHARP |
| साइज | 5.0 |
| आवेदन | MPH |
| संकल्प | 1080×1920 |
| रचना | LCM |
| चमक | 460 |
| CR | 1000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | MIPI |
| प्यानल ब्रान्ड | SHARP |
| प्यानल मोडेल | LS050T1SX12(K) |
| प्यानल प्रकार | CG-Silicon , LCM |
| प्यानल आकार | 5.0 inch |
| संकल्प | 1080(RGB)×1920 , FHD |
| प्रदर्शन मोड | New Mode2, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 61.641×109.584 mm |
| रूपरेखा | 64.041×116.224×1.13 mm |
| सतह | Hard coating (3H) |
| चमक | 460 cd/m² (Typ.) |
| विपरीत अनुपात | 1000:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193195% |
| प्रतिक्रिया समय | 35 (Max.)(Tr+Td) |
| हेर्ने कोण | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 7S2PWLEDWithout Driver |
| संकेत इन्टरफेस | MIPI (4 data lanes), 34 pins |
| इनपुट भोल्टेज | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| आवेदन | MPH |
| ACX450AKN-7 | JDI | 5.0 | 1080×1920 |
| AT050TN35 | Innolux | 5.0 | 480×272 |
| CLAA050LA0ACW | CPT | 5.0 | 800×480 |
| CLAF050LN41 TXX | CPT | 5.0 | 540×960 |
| H495TAN01.1 | AUO | 5.0 | 720×1280 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX04 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX06 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| LS050T1SX12(K) | SHARP | 5.0 | 1080×1920 |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| DX12D100VM0EAA | JDI | 4.7 | 720×1280 |
| H598QAN01.0 | AUO | 6.0 | 1440×2560 |
| HVA37WV1-D01 | HYDIS | 3.7 | 480×800 |
| LH470WX6-SD02 | LG Display | 4.7 | 750×1334 |
| LS030Y3DX01 | SHARP | 3.0 | 480×800 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TFT2N0369-E | Other | 3.2 | 240×320 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
| TM035PDH53 | Tianma | 3.5 | 320×480 |
