| भाग नम्बर | LQ097L1JY01A |
| ब्रान्ड | SHARP |
| साइज | 9.7 |
| आवेदन | PAD |
| संकल्प | 2048×1536 |
| रचना | LCM |
| चमक | 440 |
| CR | 1000:1 |
| रंगहरू | 16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | eDP |
| प्यानल ब्रान्ड | SHARP |
| प्यानल मोडेल | LQ097L1JY01A |
| प्यानल प्रकार | IGZO TFT-LCD , LCM |
| प्यानल आकार | 9.7 inch |
| संकल्प | 2048(RGB)×1536 , QXGA |
| प्रदर्शन मोड | O-mode FFS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 196.608×147.456 mm |
| सतह | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| चमक | 440 cd/m² (Typ.) |
| विपरीत अनुपात | 1000:1 (Typ.) |
| प्रदर्शन रंगहरू | 16.7M (8-bit), CIE193172% |
| प्रतिक्रिया समय | |
| हेर्ने कोण | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 7S6P×2CNWLEDWithout Driver |
| संकेत इन्टरफेस | eDP (4 Lanes), 56 pins |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | PAD |
