| भाग नम्बर | TD035STEB2 |
| ब्रान्ड | TPO |
| साइज | 3.5 |
| आवेदन | PDA |
| संकल्प | 240×320 |
| रचना | LCM |
| चमक | 100 |
| CR | 100:1 |
| रंगहरू | 262K |
| ब्याकलाइट | WLED |
| इन्टरफेस | TTL |
| प्यानल ब्रान्ड | Toppoly |
| प्यानल मोडेल | TD035STEB2 |
| प्यानल प्रकार | LTPS TFT-LCD , LCM |
| प्यानल आकार | 3.5 inch |
| संकल्प | 240(RGB)×320 , QVGA |
| प्रदर्शन मोड | TN, Normally White, Transflective |
| सक्रिय क्षेत्र | 53.64×71.52 mm |
| रूपरेखा | 64×85×4.9 mm |
| सतह | |
| चमक | 100 cd/m² (Typ.) |
| विपरीत अनुपात | 100:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| प्रदर्शन रंगहरू | 262K (6-bit), CIE193140% |
| प्रतिक्रिया समय | 10/20 (Typ.)(Tr/Td) |
| हेर्ने कोण | 55/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| बत्ती प्रकार | 6S1PWLEDWithout Driver |
| संकेत इन्टरफेस | Parallel RGB (1 ch, 6-bit), 60 pins |
| इनपुट भोल्टेज | 3.3/5.0/11.7/-6.5V (Typ.)(VCC3/VCC5/VDD/VEE) |
| आवेदन | PDA |
