| भाग नम्बर | UG-2864ASWPG01 |
| ब्रान्ड | WiseChip |
| साइज | 2.4 |
| आवेदन | IA |
| संकल्प | 128×64 |
| रचना | OLED |
| चमक | 80 |
| CR | |
| रंगहरू | Mono(White) |
| ब्याकलाइट | self |
| इन्टरफेस | CPU/SPI/I²C |
| प्यानल ब्रान्ड | WiseChip |
| प्यानल मोडेल | UG-2864ASWPG01 |
| प्यानल प्रकार | PM-OLED , OLED |
| प्यानल आकार | 2.4 inch |
| संकल्प | 128×64 |
| सक्रिय क्षेत्र | 55.01×27.49 mm |
| रूपरेखा | 60.5×37 mm |
| सतह | |
| चमक | 80 cd/m² (Typ.) |
| विपरीत अनुपात | |
| प्रदर्शन रंगहरू | Mono(White) |
| हेर्ने कोण | |
| चालक आईसी | Built-in SSD1309 |
| संकेत इन्टरफेस | 8-bit 6800/8080 parallel, 4-wire SPI, I²C |
| rohs: | |
| आवेदन | IA |
| UG-2864ASWIG01 | WiseChip | 2.7 | 128×64 |
| UG-2864ASWPG01 | WiseChip | 2.4 | 128×64 |
| UG-2864ASYCG01 | WiseChip | 1.54 | 128×64 |
| UG-2864ASYDT01 | WiseChip | 2.7 | 128×64 |
| UG-2864ASYIG01 | WiseChip | 2.7 | 128×64 |
| UG-2864HLBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
| UG-2864KLBLG01 | WiseChip | 1.3 | 128×64 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
| AA104SH02--T1 | Mitsubishi | 10.4 | 800×600 |
| AA121SL12 | Mitsubishi | 12.1 | 800×600 |
| C555001 | SII | 5.7 | 320×240 |
| G150XG01 V1 | AUO | 15.0 | 1024×768 |
| LM-EH53-22NTK | SANYO | 10.4 | 640×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LM64C21P | SHARP | 8.0 | 640×480 |
| LQ150X1LG55 | SHARP | 15.0 | 1024×768 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| TX17D200VM0BAA | KOE | 6.5 | 800×480 |
