| भाग नम्बर | UG-5664ASGEF01 |
| ब्रान्ड | WiseChip |
| साइज | 3.1 |
| आवेदन | IA |
| संकल्प | 256×64 |
| रचना | OLED |
| चमक | 120 |
| CR | 2000:1 |
| रंगहरू | Grayscale(G) |
| ब्याकलाइट | self |
| इन्टरफेस | CPU/SPI |
| प्यानल ब्रान्ड | Univision |
| प्यानल मोडेल | UG-5664ASGEF01 |
| प्यानल प्रकार | PM-OLED , OLED |
| प्यानल आकार | 3.1 inch |
| संकल्प | 256×64 |
| सक्रिय क्षेत्र | 76.78×19.18 mm |
| रूपरेखा | 88×27.8×2.1 mm |
| सतह | |
| चमक | 120 cd/m² (Typ.) |
| विपरीत अनुपात | 2000 : 1 (Typ.) |
| प्रदर्शन रंगहरू | Grayscale(G) (4-bit) |
| हेर्ने कोण | 80/80/80/80 (Min.)(L/R/U/D) |
| चालक आईसी | COF Built-in SSD1322 |
| संकेत इन्टरफेस | 8-bit 6800/8080 parallel, 3/4-wire SPI, 30 pins |
| इनपुट भोल्टेज | 2.8/12V (Typ.)(VCI/VCC) |
| rohs: | |
| आवेदन | IA |
| UG-5664ALBDF01 | WiseChip | 2.8 | 256×64 |
| UG-5664ALBEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASGEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASGGF01 | WiseChip | 5.5 | 256×64 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASYEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASYGF01 | WiseChip | 5.5 | 256×64 |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| G104SN02 V0 | AUO | 10.4 | 800×600 |
| G240UAN01.0 | AUO | 24.0 | 1920×1200 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL128102AC29-17 | NLT | 19.0 | 1280×1024 |
| NL8048BC19-02 | NLT | 7.0 | 800×480 |
| NLB150XG01L-01 | NLT | 15.0 | 1024×768 |
| OEL9M0065-Y-E | Other | 2.7 | 256×64 |
| SP19V001-ZZC | KOE | 7.5 | 640×480 |
