| भाग नम्बर | CLAA102NB01XV |
| ब्रान्ड | CPT |
| साइज | 10.2 |
| आवेदन | IA |
| संकल्प | 1024×600 |
| रचना | LCM |
| चमक | 400 |
| CR | 700:1 |
| रंगहरू | 262K/16.2M |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | CPT |
| प्यानल मोडेल | CLAA102NB01XV |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 10.2 inch |
| संकल्प | 1024(RGB)×600 , WSVGA |
| प्रदर्शन मोड | HFFS, Normally Black, Transmissive |
| सक्रिय क्षेत्र | 222.72×130.5 mm |
| रूपरेखा | 235×147×5.4 mm |
| सतह | Antiglare |
| चमक | 400 cd/m² (Typ.) |
| विपरीत अनुपात | 700:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.2M (6-bit / 6-bit + FRC), CIE193160% |
| प्रतिक्रिया समय | 30 (Typ.)(Tr+Td) |
| हेर्ने कोण | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | 4S12PWLEDWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 8-bit), 60 pins |
| इनपुट भोल्टेज | 3.3/13/18/-6V (Typ.)(VDD/AVDD/VGH/VGL) |
| आवेदन | IA |
