| भाग नम्बर | NL10276BC20-37 |
| ब्रान्ड | NLT |
| साइज | 10.4 |
| आवेदन | IA |
| संकल्प | 1024×768 |
| रचना | LCM |
| चमक | 150 |
| CR | 400:1 |
| रंगहरू | 262K/16.7M |
| ब्याकलाइट | WLED |
| इन्टरफेस | LVDS |
| प्यानल ब्रान्ड | NLT |
| प्यानल मोडेल | NL10276BC20-37 |
| प्यानल प्रकार | a-Si TFT-LCD , LCM |
| प्यानल आकार | 10.4 inch |
| संकल्प | 1024(RGB)×768 , XGA |
| प्रदर्शन मोड | TN, Normally White, Transmissive |
| सक्रिय क्षेत्र | 210.4×157.8 mm |
| रूपरेखा | 231.2×174.6×5.8 mm |
| सतह | Clear |
| चमक | 150 cd/m² (Typ.) |
| विपरीत अनुपात | 400:1 (Typ.) |
| प्रदर्शन रंगहरू | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| प्रतिक्रिया समय | 3/15 (Typ.)(Tr/Td) |
| हेर्ने कोण | 45/45/40/20 (Typ.)(CR≥10)(L/R/U/D) |
| आवृत्ति | 60Hz |
| बत्ती प्रकार | WLEDWithout Driver |
| संकेत इन्टरफेस | LVDS (1 ch, 6/8-bit) |
| इनपुट भोल्टेज | 3.3V (Typ.) |
| आवेदन | IA |
